Nautilus Hyosung Monimax 5600 Lobby ATM Machine

  • 1
  • 2

Brand Name : Nautilus Hyosung

Model Number : Nautilus Hyosung Monimax 5600

Certification : CE

Place of Origin : China

MOQ : 1pc

Price : Negociate

Payment Terms : TT,Paypal,Western Union,LC

Supply Ability : 50pcs/week

Delivery Time : 2-3 day

Packaging Details : Carton

Brand : Nautilus Hyosung

Part Number : Nautilus Hyosung Monimax 5600

Description : Nautilus Hyosung Monimax 5600 Lobby ATM Machine

Material : Metal

Conditional : New Original

MOQ : 1pc

Contact Now

Nautilus Hyosung Monimax 5600 Lobby ATM Machine


Product Description

Product name Nautilus Hyosung Monimax 5600 Lobby ATM Machine
Part Number Nautilus Hyosung Monimax 5600
Condition New Original/Refurbished
Warranty 90 days
Packing Inner with plastic bag, outer with carton
Delivery 1-7 days after payment

Nautilus Hyosung MoniMax 5600 (Lobby Version) is a floor-standing, walk-up cash dispenser designed for indoor lobby environments (banks, retail, offices). It features front access for easy maintenance and high reliability for high-traffic indoor use.


1. Core Overview


  • Model: MoniMax 5600 (Lobby / Walk-Up)
  • Installation: Freestanding, Indoor Lobby
  • Key Features: Front-service design, compact footprint, EMV compliance, multi-cassette cash handling
  • Target Use: Bank lobbies, corporate offices, high-traffic retail spaces


2. Hardware Specifications


Component Specification
Display 15" TFT LCD, XGA 1024×768, Anti-glare, 16.2M colors
Touchscreen Resistive touch (standard)
Privacy Filter Optional (15.1")
Input Methods Touchscreen + 8 function keys (optional)
PIN Pad (EPP) PCI-compliant, Encrypting PIN Pad, supports T-DES/DES/RSA
Audio Speaker + Earphone jack (ADA audio guidance)

Card Reader


Type Compliance Features
Dual Card Reader EMV Level 1/2, ISO 7816 DIP (manual) + Motorized hybrid (magnetic stripe + IC)
Contactless Optional Integrated NFC (supports cards, smartphones, smartwatches)
Anti-fraud Standard Anti-skimming, anti-card trapping, anti-shimming

Cash Dispensing Unit (CDU)


  • Cassette Configuration: Up to 4 cash cassettes + 1 retract bin (total 5 modules)
  • Capacity: 3,000 notes per cassette (max 12,000 notes total)
  • Dispense Speed: Up to 50 notes per transaction
  • Features: Automatic note shutter, note-by-note rejection, bundle present/retract, multi-denomination support
  • Access: Front-loading for quick replenishment

Printers


  • Receipt Printer: 80mm graphical thermal printer, semi-automatic paper loading
  • Journal Printer: Optional (MDP-350 dot impact printer, 76mm width)

Main System


  • CPU: Intel Pentium 4 / Celeron (legacy) / Modern equivalent
  • Memory: 1GB DDR3 (upgradable)
  • Storage: 160GB HDD (standard) / 128GB SSD (optional)
  • OS: Windows 7 Embedded (standard) / Windows 10 (newer models)
  • XFS: Hyosung Moniplus™ XFS 3.10 or later
  • Ports: Gigabit LAN (10/100/1000Mbps), 8×USB, 6–8×RS232, Mini PCI-E expansion

Security & Safety


  • Safe: UL 291 Level 1 certified (CEN optional)
  • Locks: Mechanical combination lock, electronic lock, KABA Mas/Cencon lock (optional)
  • Alarms: Heat + seismic sensors, door status sensor
  • Tampers: Physical/electronic tamper detection, anti-tamper enclosures
  • Cameras: Optional internal security camera (face/hand detection)

Power & Environment


  • Power Input: 100–240V AC, 50/60Hz, 250W max
  • Backup Battery: For safe shutdown and last transaction retention
  • Operating Temp: 0°C ~ 40°C (32°F ~ 104°F)
  • Storage Temp: -10°C ~ 60°C (14°F ~ 140°F)
  • Humidity: 25%–86% (operating, non-condensing); 10%–90% (storage)
  • Dimensions (H×W×D): 1,440 × 460 × 840 mm (58.6" × 18.1" × 33.1")
  • Weight: ~350 kg (771.6 lbs)


3. Optional Modules


  • Contactless NFC Card Reader
  • Barcode Scanner (1D/2D)
  • Biometric Fingerprint Reader
  • Additional Security Cameras
  • Privacy Filter
  • ADA-Compliant Audio Guidance System

  • Nautilus Hyosung Monimax 5600 Lobby ATM Machine

    Nautilus Hyosung Monimax 5600 Lobby ATM Machine
